- Powerful, stable and accurate cutting via the inverted T-shape X/Z axis of the box guideway bed - Powerful cutting via the gear-type high-torque spindle - Peerless capabilities to machine general and hard-to-cut metal based on the high-rigidity structure - Higher productivity and reliability via the speedy servo drive tool / pallet change
| Технические характеристики: | |||||||||
| NHM 5500 | NHM 6300 | NHM 8000 | |||||||
| Pallet Size | mm | 500 x 500 | 630 x 630 | 800 x 800 | |||||
| Tooling Taper | taper | 50 | 50 | 50 | |||||
| Max. Spindle Speed | r/min | 6000 | 6000 | 6000 | |||||
| Max. Spindle Motor Power | kW | 25 | 35 | 35 | |||||
| Travel (X / Y / Z) | mm | 800 / 700 / 850 | 1050 / 850 / 1000 | 1400 / 1050 / 1200 | |||||
| Tool Storage Capacity | ea | 60 | 60 | 60 | |||||
| NC System | - | FANUC / SIEMENS | FANUC / SIEMENS | FANUC / SIEMENS | |||||
